Product Details
Plano 3D Green Line Laser
With the Plano 3D Green, all you need to do is set it up and turn it on, and it will instantly project precise laser lines across the room. The laser lines can be individually activated at the push of a button, offering a wide range of applications for simultaneous marking, alignment, and leveling.
This line laser is available exclusively with the Pro Measurement Set.
Sharp Laser Lines Across the Entire Workspace
The vertical lines, combined with the 360° horizontal laser line, create a precise 90° angle, forming cross points on walls, ceilings, and floors.
This precise vertical alignment allows for quick and easy transfer of measurement points, such as when installing light fixtures or ceiling panels.
The exact 90° angle is perfect for accurately aligning installations like cabinets and furniture, and it also assists with tasks such as erecting walls and suspending ceilings.
Technische Daten
| Dimensions | 150 x 95 x 125 mm |
| Leveling | Self-leveling |
| Measuring tolerance | ±0.30 mm/m |
| Self-leveling range | ±3° |
| Application range without handheld receiver (radius) | 30 m* |
| Application range with handheld receiver (radius) | 80 m* |
| Operating temperature | -10 °C bis +50 °C |
| Tripod adapter | 1/4″ + 5/8″ |
| Protection class | IP 54 |
| Power supply | 2 x 3.6 V (18650) Li-ion battery (2 x 3450 mAh) |
| Operating time (at 20 °C) | 8 h |
| Laser class | 2, DIN EN 60825-1 : 2014 |
| Output power | < 1.0 mW |
| Wavelength | 505 – 520 nm < 1mW |
| Charging cable | 83 cm |
